Brand Name : | WNRLN |
Model Number : | WXTK032 |
Price : | Competitive |
Payment Terms : | Western Union,T/T,Paypal,MoneyGram |
Supply Ability : | 50000pcs Per Month |
Delivery Time : | 10-30 Days |
Certification : | SGS/ISO9001 |
24V Auto Ac Compressor System 5095365 SD7H15U6473 For Standard For Various For JCB WXTK032
Parameter:
Compressor Model | 7H15 |
Diameter | Standard Size |
Grooves | 2PK |
Model no. | WXTK032 |
Car Make | For Standard For Various For JCB |
OEM | 50914052/5095365/SD7H15U6473/SD7H15333 |
Automobile air conditioning compressor composition
1. Compressor Housing: The compressor housing encloses all the internal components of the air conditioning compressor and provides support and protection.
2. Compressor Shaft Seal: The shaft seal prevents refrigerant and
oil from leaking out of the compressor.
3. Swash Plate: The swash plate is connected to the compressor
shaft and helps to regulate the movement of the pistons inside the
compressor.
4. Piston Assembly: The piston assembly moves up and down within
the cylinders of the compressor to compress the refrigerant gas.
5. Swash Plate Bearings: These bearings support the swash plate and
allow it to rotate smoothly.
6. Cylinder Head: The cylinder head contains the reed valves and
serves as the top cover of the compressor cylinders.
7. Reed Valves: Reed valves are located in the cylinder head and
control the flow of refrigerant gas into and out of the compressor
cylinders.
8. Suction and Discharge Ports: These ports enable the entry and
exit of refrigerant gas into and out of the compressor cylinders.
9. Clutch Assembly: The clutch assembly engages and disengages the
compressor from the engine, allowing the compressor to turn on and
off as needed.
10. Electronic Control Module (ECM): The ECM monitors and controls
the operation of the air conditioning compressor, ensuring optimal
performance and efficiency.
