977013E200 Air Conditioning Compressor Car For Kia Sorento 3.5
WXKA040
The automobile air conditioning compressor is the core component of
the automobile air conditioning system. It achieves rapid cooling
of the air in the car by compressing low-pressure cold gas into
high-pressure and high-temperature gas. Our compressors have the
advantages of efficient refrigeration capacity, low energy
consumption, low noise and reliability, providing drivers with a
comfortable driving experience. We are committed to providing
customers with high-quality, high-performance automotive air
conditioning compressors and contributing to the comfortable
driving experience in the automotive industry.
Parameter:
Model Number
| WXKA040
|
Car Model
| For Kia Sorento 3.5
|
Type
| Ac Compressor
|
Year Model
| 2006-2013
|
Compressor type
| HS18
|
OE No
| 977013E200/977013E200RU
|
Qualification Certificate
Common problems with automobile air conditioning compressors:
1. Refrigerant leaks: Over time, the refrigerant in the AC system
can develop leaks, resulting in reduced cooling performance and
potential damage to other components.
2. Compressor problems: The compressor is responsible for
circulating the refrigerant and is prone to wear and tear. Common
issues include compressor failure, clutch problems, or leaks.
3. Blower motor malfunction: The blower motor blows air into the
cabin. If the motor fails or malfunctions, it can lead to weak
airflow or no airflow at all.
4. Condenser troubles: The condenser, located at the front of the
vehicle, can be damaged by debris, rocks, or accidents. A damaged
condenser may reduce cooling efficiency.
5. Electrical issues: Problems with electrical components such as
faulty wiring, blown fuses, or malfunctioning switches can affect
the AC system's operation.
6. Blocked or clogged vents: Accumulated dust, debris, or objects
obstructing the vents can restrict airflow and decrease the AC
system's cooling capacity.
7.Expansion valve or evaporator problems: Issues with the expansion
valve or evaporator, such as clogs or leaks, can lead to improper
cooling and inadequate temperature regulation.
Piston-Type Compressors
The automotive air conditioning compressor is a crucial component
of the AC system, responsible for compressing and circulating the
refrigerant. It consists of several key parts that work together to
achieve effective cooling.
1. Compressor Housing: The outer shell of the compressor, designed
to enclose and protect the internal components.
2. Compressor Pulley: A pulley attached to the front of the
compressor, connected to the engine via a belt. It transfers power
from the engine to drive the compressor.
3. Clutch Assembly: The clutch allows the compressor to engage and
disengage as required. It consists of an electromagnetic coil,
friction plates, and a hub.
4. Swash Plate: This component converts the rotational motion of
the compressor shaft into a reciprocating or up-and-down motion. It
is responsible for compressing the refrigerant.
5. Piston: Linked to the swash plate, the piston moves up and down
within the compressor cylinder to compress the refrigerant gas.
6. Reed Valves: These one-way valves control the flow of
refrigerant into and out of the cylinder. They prevent backflow and
ensure efficient compression.
7. Oil Separator: Located within the compressor housing, it
separates the refrigerant oil from the refrigerant gas before it
leaves the compressor.
8. Shaft Seal: This seal prevents refrigerant from leaking out and
contaminants from entering the compressor. It ensures the integrity
of the system.
9. Control Valve: Some compressors have a control valve that
regulates the flow of refrigerant based on the cooling demands of
the vehicle.
10. Mounting Brackets: These brackets secure the compressor to the
engine or chassis, keeping it stable and in the correct position.
Each of these components plays a crucial role in the operation of
the automotive air conditioning compressor. Their proper
functioning ensures efficient cooling and overall performance of
the AC system in vehicles.
